Luminor BLACKCOMB All-In-One UV + Filtration System – 15 GPM

Model: LBH5-Z222-NC

Get complete, whole-home water protection with a powerful system that combines advanced filtration and UV disinfection in one streamlined setup.

The Luminor BLACKCOMB-HO 5.1 is engineered to protect against harmful microorganisms like E. coli and coliform bacteria, while giving you the flexibility to customize filtration based on your water quality. Ideal for homes, cottages, and cabins, this system delivers reliable, chemical-free disinfection with professional-grade performance.

With three 20" Big Blue filter housings, this system allows for robust multi-stage filtration before UV treatment—helping maximize UV effectiveness and overall water quality throughout your home.

---

Why This System Stands Out

✔️ All-in-one solution — filtration + UV disinfection in one integrated system
✔️ 15 GPM high-output capacity for full-home coverage
✔️ UV disinfection neutralizes bacteria like E. coli and coliform
✔️ Triple 20" filter housings allow for customized multi-stage filtration
✔️ Horizontal UV chamber for easier installation in tight spaces
✔️ Reversible design for flexible plumbing configurations
✔️ Made in Canada with premium, long-lasting components

---

Smart Monitoring + Low Maintenance

✔️ Lamp countdown timer ensures timely replacement
✔️ Visible + audible alarms for system status and safety
✔️ Extended lamp life — up to 10,000 hours (~14 months)
✔️ Low energy consumption — just 57 watts

---

Built for Long-Term Reliability

✔️ 316L stainless steel reactor + manifold for superior durability and corrosion resistance
✔️ Axial flow design ensures consistent UV exposure
✔️ 1” MNPT connections for easy integration into most plumbing systems
✔️ Compatible with add-ons like UV sensor, solenoid shutoff, remote alarm, and more

---

Performance Specs

• Flow Rate: 15 GPM (at 95% UVT)
• UV Dose: 30 mJ/cm²
• Reactor Size: 20” L × 3.5” W
• Power Consumption: 57W

---

Dimensions

9.5” D × 26.5” W × 33.5” H

---

Important Note

Filter cartridges are not included and should be selected based on your specific water conditions.

---

Replacement Parts

• Lamp: RL-420HO
• Sleeve: RQ-420
• Controller: RCHO-56.12

---

Warranty

• 10 years: stainless steel reactor
• 3 years: electronics
• 1 year: UV lamp and sleeve

---

Product #: UVS LBH5-Z222-NC
